70degree high temp heat pumpCurrent Location ：Home > PRODUCTS> High Temp air source heat pump> 70degree high temp heat pump
- high quality heating capacity is 11kw high temp heat pump unit(70degree)
- 【Brief】：
- 【Series】：70degree high temp heat pump
- Description
-
High temperature heat pump (70℃ hot water) Model unit FAT-03 FAT-04 Performance Heating capacity kw 8 11 Btu/h 27304 36587 Hot water supply T/h 0.14 0.18 Rated power kw 2.5 3.32 Rated current A 12.3 16 COP kw/kw 3.2 3.4 Max rating current A 17.1 20 Power supply V/Ph/Hz 220V/380V~50Hz Noise dB(A) 53 55 Dimension Width mm 680 648 Depth mm 635 624 Height mm 820 840 Unit weight kg 115 145 Operating control Precision of temp contrl ℃ ±1℃ Operating range ℃ –15–43℃ Structure Throtting type Electronic expansion valves Refrigerant Type R417A Discharge kg 1.7 1.84 Compressor Type Copeland /panasonic scroll Quantity piece 1 1 Air side heat exchanger Type Finned heat exchange Powder kw 0.2 0.24 Hot water side heat exchange Type Efficient tube in shell heat exchanger Water flow m3/h 1.38 1.84 Water drop kpa 21 24 Connecting dimension Inch 3/4 1 Water side max rating pressure kpa 1000 1000 Rated hot water working conditon:air source air inlet dry bulb temp is 20℃,wet buld temp is 15℃,inital temp of hot water is 20℃, termination temp of hot water is 70℃.
