- 8.8kw swimming pool heat pump spa heater air to water heat pump
- 【Brief】：
- 【Series】：Swimming pool heat pump
- Description
-
Swimming pool heat pump/spa heat pump Model heat pump FAP-02 function Rated heating capacity kW 8.8 BTU 26621 Rated input power kW 1.5 Rated heating input current A 7.5 COP kW/kW 5.2 Max running current A 9.70 Power source 220V/50Hz Noise level dB(A) 45 Dimention Width mm 1000 Depth mm 350 Height mm 620 Weight kg 85 Water temperature control precision ±2℃ Working environment —15℃~43℃ Throttle type Electronic expansion valves/thermal expansion valves Refrigerant Type R417A, R407C,R410A Compressor Brand /type Panasonic Qty pc 1 Heat source side Heat exchange type Efficient finned tube exchanger Motor power fan type Axial flow fan Motor power kW 0.1 Hot water side Heat exchanger type High titanium tube heat exchanger Water flow m3/h 1.75 Water pressure drop kPa 12 Connect pipe size Inch 1 Water size max work pressure kPa 600 Rated heating working conditions: air-source air inlet dry bulb temp is 24,wet bulb temp is 19℃, water side inlet temp28℃, outlet temp32℃
