Model

heat pump

FAP-015

function

Rated heating capacity

kW

5.5

BTU

18771

Rated input power

kW

0.99

Rated heating input current

A

4.5

COP

kW/kW

5.2

Max running current

A

7.0

Power source

220V/50Hz

Noise level

dB(A)

40

Dimention

Width

mm

750

Depth

mm

300

Height

mm

510

Weight

kg

65

Water temperature control precision

±2℃

Working environment

—15℃~43℃

Throttle type

Electronic expansion valves

Refrigerant

Type

R417A, R407C,R410A

Compressor

Brand /type

hitachi

Qty

pc

1

Heat source side

Heat exchange type

Efficient finned tube exchanger

Motor power fan type

Axial flow fan

Motor power

kW

0.1

Hot water side

Heat exchanger type

High titanium tube heat exchanger

Water flow

m³/h

1.9

Water pressure drop

kPa

10

Connect pipe size

Inch

1

Water size max work pressure

kPa

600
