- 20kw Monoblock Low temperature EVI Air to water heat pump
- 【Brief】：operation in cold weather -25℃ max outlet hot water temp +55℃ for sanitary hot water and under floor
- 【Series】：Monoblock Low temperature EVI heat pump
- Description
-
Name: Monoblock Low temperature EVI Air to water heat pump Model heat pump FA-05EVI Unit function Standard condition Heating capacity kw 20.3 kcal/h 17455 Hot water supply T/h 0.44 Input power kw 4.8 Low temperature conditions Heating capacity kw 16.6 kcal/h 14273 Hot water supply T/h 0.32 Input power kw 4.69 Ultra-low temperature conditions Heating capacity kw 9.7 kcal/h 8340 Hot water supply T/h 0.19 Input power kw 4.15 Standard condition heating input current A 8.4 Max running current A 12 Power V/Ph/Hz 380V/3N/50Hz Unit Noise comprehensive index Db(A) 58 Unit weight kg 145 Running control Water temperature control precision ℃ ±2℃ Ambient temperature range ℃ –25℃ – 43℃ Refrigerants circulation structure Throttle type Electric expansion valve Refrigerant Type R407C Refrigerant charge kg 3.5 Max working pressure bar 28 Compressor Type Efficient fully enclosed type vortex Stall Current A 60 Air-source side heat exchanger Type Finned heat exchanger Qty pc 1 Motor power kw 0.4 Hhot water side heat exchanger Type Efficient tube to tube heat exchange Water flow m3/h 3.49 Connecting pipe size DN 25
